pbsvは、PacBio一分子リアルタイムシークエンシング(SMRT)リードから二倍体ゲノムの構造変異をコールして分析するための一連のツールである。 このツールは、PacBioのSMRT Link GUIのStructural Variant Calling分析ワークフローを強化する。
pbsvは挿入、欠失、逆位、duplications、および転座をコールする。シングルサンプルコールとジョイント(マルチサンプル)コールの両方がサポートされている。
pbsvの効果的な範囲
- 20 bpから10 kbまでの挿入
- 20塩基対から100塩基対までの欠失
- 200 bpから10 kbへの逆位
- 20 bpから10 kbまでのduplications
- 異なる染色体間の転座、あるいは単一の染色体上で100kb以上離れている
Structural Variant Detection in SMRT Link 5 with pbsv
インストール
ubuntu16.04でテストした(ホストOS macos10.12)。
PacBio Secondary Analysis Tools on Bioconda
本体 Github
#anacondaを使っているならcondaで導入可能(linux only)
conda install -c bioconda pbsv
#pbmm2がないならこちらも入れる
conda install -c bioconda pbmm2
> pbsv
# pbsv
pbsv - PacBio structural variant (SV) calling and analysis tools
Usage: pbsv <tool>
Basic Options:
-h, --help Output this help.
--version Output version information.
Tools:
discover Find structural variant signatures in read alignments (BAM to SVSIG).
call Call structural variants from SV signatures and assign genotypes (SVSIG to VCF).
Typical workflow:
1. Align PacBio reads to a reference genome, per movie.
Subreads BAM input:
$ pbmm2 align ref.fa movie1.subreads.bam ref.movie1.bam --sort --median-filter --sample sample1
CCS BAM input:
$ pbmm2 align ref.fa movie1.ccs.bam ref.movie1.bam --sort --preset CCS --sample sample1
CCS FASTQ input:
$ pbmm2 align ref.fa movie1.Q20.fastq ref.movie1.bam --sort --preset CCS --sample sample1 --rg '@RG\tID:movie1'
2. Discover signatures of structural variation (per movie or per sample):
$ pbsv discover ref.movie1.bam ref.sample1.svsig.gz
$ pbsv discover ref.movie2.bam ref.sample2.svsig.gz
3. Call structural variants and assign genotypes (all samples), for CCS input append "--ccs":
$ pbsv call ref.fa ref.sample1.svsig.gz ref.sample2.svsig.gz ref.var.vcf
root@908d5cac1b6e:/#
> pbsv discover
$ pbsv discover
Usage: pbsv discover [options] <ref.in.bam|xml> <ref.out.svsig.gz>
pbsv discover - Find structural variant (SV) signatures in read alignments (BAM to SVSIG).
Basic Options:
-h,--help Output this help.
--version Output version information.
--log-file Log to a file, instead of stderr.
--log-level Set log level: "TRACE", "DEBUG", "INFO", "WARN", "FATAL". ["WARN"]
Sample Options:
-s,--sample Override sample name tag from BAM read group.
Alignment Filter Options:
-q,--min-mapq Ignore alignments with mapping quality < N. [20]
-m,--min-ref-span Ignore alignments with reference length < N bp. ["100"]
Downsample Options:
-w,--downsample-window-length Window in which to limit coverage, in basepairs. ["10K"]
-a,--downsample-max-alignments Consider up to N alignments in a window; 0 means disabled. [20]
Discovery Options:
-r,--region Limit discovery to this reference region: CHR|CHR:START-END.
-l,--min-svsig-length Ignore SV signatures with length < N bp. ["7"]
-b,--tandem-repeats Tandem repeat intervals for indel clustering.
-k,--max-skip-split Ignore alignment pairs separated by > N bp of a read or reference. ["100"]
Options:
--emit-tool-contract Emit tool contract.
--resolved-tool-contract Use args from resolved tool contract.
Arguments:
ref.in.bam|xml Coordinate-sorted aligned reads in which to identify SV signatures.
ref.out.svsig.gz Structural variant signatures output.
> pbsv call
# pbsv call
Usage: pbsv call [options] <ref.fa|xml> <ref.in.svsig.gz|fofn> <ref.out.vcf>
pbsv call - Call structural variants from SV signatures and assign genotypes (SVSIG to VCF).
Basic Options:
-h,--help Output this help.
--version Output version information.
--log-file Log to a file, instead of stderr.
--log-level Set log level: "TRACE", "DEBUG", "INFO", "WARN", "FATAL". ["WARN"]
-j,--num-threads Number of threads to use, 0 means autodetection. [0]
-z,--chunk-length Process in chunks of N reference bp. ["1M"]
Variant Options:
-t,--types Call these SV types: "DEL", "INS", "INV", "DUP", "BND", "CNV". ["DEL,INS,INV,DUP,BND,CNV"]
-m,--min-sv-length Ignore variants with length < N bp. ["20"]
--min-cnv-length Ignore CNVs with length < N bp. ["1K"]
--max-ins-length Ignore insertions with length > N bp. ["10K"]
--max-dup-length Ignore duplications with length > N bp. ["100K"]
SV Signature Cluster Options:
--cluster-max-length-perc-diff Do not cluster signatures with difference in length > P%. [25]
--cluster-max-ref-pos-diff Do not cluster signatures > N bp apart in reference. ["200"]
--cluster-min-basepair-perc-id Do not cluster signatures with basepair identity < P%. [10]
Consensus Options:
-x,--max-consensus-coverage Limit to N reads for variant consensus. [20]
-s,--poa-scores Score POA alignment with triplet match,mismatch,gap. ["1,-2,-2"]
--min-realign-length Consider segments with > N length for re-alignment. ["100"]
Call Options:
-A,--call-min-reads-all-samples Ignore calls supported by < N reads total across samples. [2]
-O,--call-min-reads-one-sample Ignore calls supported by < N reads in every sample. [2]
-S,--call-min-reads-per-strand-all-samples Ignore calls supported by < N reads per strand total across samples [1]
-P,--call-min-read-perc-one-sample Ignore calls supported by < P% of reads in every sample. [20]
--ccs CCS optimized parameters: -A 1 -O 1 -S 0 -P 10.
Genotyping:
--gt-min-reads Minimum supporting reads to assign a sample a non-reference genotype. [1]
Annotations:
--annotations Annotate variants by comparing with sequences in fasta. Default annotations are ALU, L1, SVA.
--annotation-min-perc-sim Annotate variant if sequence similarity > P%. [60]
Variant Filtering Options:
--min-N-in-gap Consider >= N consecutive "N" bp as a reference gap. ["50"]
--filter-near-reference-gap Flag variants < N bp from a gap as "NearReferenceGap". ["1K"]
--filter-near-contig-end Flag variants < N bp from a contig end as "NearContigEnd". ["1K"]
Options:
--emit-tool-contract Emit tool contract.
--resolved-tool-contract Use args from resolved tool contract.
Arguments:
ref.fa|xml Reference genome assembly against which to call variants.
ref.in.svsig.gz|fofn SV signatures from one or more samples.
ref.out.vcf Variant call format (VCF) output.
実行方法
1、リファレンスにマッピングする。pbmm2(紹介)(インストール参照)の使用が推奨されている。
subreads.bam(説明)を入力とする。
pbmm2 align ref.fa movie1.subreads.bam ref.movie1.bam --sort --median-filter --sample sample1
またはccs.bamを入力とする。
pbmm2 align ref.fa movie1.ccs.bam ref.movie1.bam --sort --preset CCS --sample sample1
またはfastqを入力とする。
pbmm2 align ref.fa movie1.Q20.fastq ref.movie1.bam --sort --preset CCS --sample sample1 --rg '@RG\tID:movie1'
unaligned.bam/fastqからマッピング結果のbamが出力される。
2、pbsv discoverでSVのシグネチャを検出
sample1と2があるなら、それぞれに対して実行。タンデムリピートのbedファイルがあるなら、感度とrecall改善のためにフラグを立てることが推奨されている("--tandem-repeats repeat.bed")。
pbsv discover ref.movie1.bam ref.sample1.svsig.gz
pbsv discover ref.movie2.bam ref.sample2.svsig.gz
ref.sample1.svsig.gz、 ref.sample2.svsig.gzが出力される。
3、pbsv callでSV検出(joint callも可能)
sample1と2があるなら両方指定する。
pbsv call ref.fa ref.sample1.svsig.gz ref.sample2.svsig.gz ref.var.vcf
ラージゲノムの場合、2以降のプロセスは並行して実行することでかなり高速化できる(*1)。実行例はpbsvのGithubを参照してください。検出アルゴリズムについてもGithubで説明されています。
引用
GitHub - PacificBiosciences/pbsv: pbsv - PacBio structural variant (SV) calling and analysis tools
関連
*1
マッピングをchromosomeごとに分けてやらないこと。
